Ingenious Upvc Gear box Door Lock Centre Case Double Spindle

Description

Ingenious Lock Case Multi Point Door Gearbox

The Ingenious Lock Case is Commonly used in UPVC  and Composite Doors. This Lock Operates with a Lift Lever Function. However as it is Duel Spindle it also allows a Night Latch Function if Required. Available in Various Back Set Sizes.

Features :

• Latch & Hook
• Back Set = 35mm & 45mm
• Top PZ = 92mm    ( Centre of Top Spindle to Centre of Euro Profile )
• Bottom PZ = 62mm   ( Centre of Bottom Spindle to Centre of Euro Profile )
• Case Height = 230mm
• Case Width = Back Set + 13mm
• Spindle Size = 8mm
• Euro Profile
• Lift Lever Function

This Ingenious Lock Case is Non Handed allowing it to be reversed by undoing the small Cross Headed Screw Located in the Latch.

Split Spindles for this Lock Case are not included , they are sold Separately.
